YET870-V2.0 Dual Motor Swing Arm Door Controller | Intelligent Control Core for Double Open Doors

For villa yards and factory perimeter swing gates, reliable performance, safety and flexible functions rely heavily on the gate controller. YET870-V2.0 is designed for dualmotor swing-gate systems, compatible with 24VDC swing-arm and in-ground gate operators, ideal for new installations and retrofitting projects.

Safety stands first for residential and commercial gates. Adjustable obstacle-detection rebound force triggers instant reversal when the gate hits people or obstacles to prevent injuries. Two independent infrared photocell inputs support configurable safety logic. Built-in motor over-current and overload protection detects malfunctions, with fault codes shown on digital tube for quick troubleshooting. It supports external 12V / 24V electromagnetic lock to boost perimeter security.

Rich configurable functions fit diverse site requirements. Single-leaf / double-leaf gate mode is selectable: run both leaves synchronously or open only one leaf for pedestrian passage. Auto-close delay ranges from 0-360 seconds for automatic gate closure after passing. Independent open-delay and close-delay settings optimize sequence for double-leaf gates and avoid leaf-to-leaf collision. Running speed, soft-stop speed and starting force are multi-level adjustable for smooth, low-noise operation with less mechanical wear. Pre-flash warning-light function triggers lamp flashing before gate movement to alert nearby people.

Both remote and local manual control are available. Remote receiving distance reaches over 50 meters in open space, storing up to 100 remote keys for multi-user access. Separate remote-coding modes for single-gate and double-gate control; long-press to clear all remotes for quick permission reset. External manual switch terminal is reserved for onsite operation. 24V backup-battery input keeps the gate working during power failure, perfect for unstable outdoor power supply.
