1, Technology parameter:

Operating Voltage: 12-24V DC

Standby Current: 15mA
Operating Frequency: 315, 433MHz
Frequency Deviation: 0.2MHz

Operating Temp: -40C~+60C
RF Sensitivity: >103dBm
Modulation Mode: ASK
Remote control capacity: 400 codes

Channel :2 channels

How to work?

Press the learning button on the receiver and then release it after LED lamp is lit and
the receiver enters into the learning state (At this moment, L E D lamp is off). After that,
press the remote control button that is required to control the controller. If LED lamp
on the receiver flashes for 5 times and then is off, it indicates that the learning is
success. The remote controller, studied by the learning button 1 on the controller,
corresponds to the relay 1; likewise , the learning button 2 corresponds to the relay 2.
Once the learning starts, only inching is available.
If the remote control is lost and it intends to fail the entire remote controller, long press
the learning button 1 or the learning button 2 (more than 5S) until LED lamp is off and
then the receiver will automatically clear the memory contents. If it is to be reused,
just study it once again.
