Single Channel Boom Barrier Gate Control Inductive Loop Vehicle Detector

ILD-500
Quantity
Contact Now

Single Channel Boom Barrier Gate Control Inductive Loop Vehicle Detector

Product Description
Single Channel Loop Vehicle Detector Highlights
  • High-temperature stability, used in kinds of environment
  • High sensitivity adjustable range
  • Environment drifting compensate automatically
  • Multilevel lightning protection
  • With the function of sensing loop malfunction automatically (disconnection or cutting-out)
  • Cooperate with barrier gate to realize vehicle anti-hit and automatic close function
  • Detect the vehicles driving direction with two loops

Single Channel Loop Vehicle Detector Function&feature
Loop Vehicle Detector is a ring for single induction coil buried digital intelligent metal detector is mainly used to detect vehicles and metal objects.
  • 10 sensitivity settings - gives the user the ability to select the best sensitivity level.
  • ILD-500 has four-way output relays.
  • ILD-500 can connect double loops so it'a have the judge direction function.
  • ILD-500 has the function to count the vehicle flux.
Application
  • Safeguarding accessways
  • For counting vehicles.
  • For controlling door
  • Gate drive mechanisms
  • Operating barriers
  • Activating card dispensers in parking lots
  • Parking system
Loop Vehicle Detector Technical Parameters:


Dimension

118*100*70mm (L*W*H)

Supply voltage

110V AC ±10% 220V AC ±10%

Frequency range

 20 kHz to 170 kHz

Sensitivity range

10 grades adjustable ( 0-9 level)

Reaction time

10ms

Output

Four-way output relays

Operating temp

-30℃ to +70℃

Storage Temp

-40℃ to +85℃

Loop inductance

Ideal 100μH to 300μH (include connecting wiring)

Max 50μH—1000μH (include connecting wiring)

Loop connection wiring

< 100 meters, twisted at least 20 times per meter


Loop Detector
Loop Vehicle Detector
Loop Vehicle Detector
Vehicle Loop Detector
Loop Detector
Vehicle Detector
Loop Vehicle Detector
Vehicle Loop Detector
